Appendix
Part Numbers and Marking Codes
NVE’s part number format consists of two or three letters, then three numbers, a dash, and then two
more numbers, and in some cases a final letter. Here is an example:
AAH004-00E
The meanings of the numbers and letters are defined as follows:
First Two
Letters
AA
AB
AD
AG
AK
BD
DB
DC
DD
Third Letter
H
L
V
Three Digits
xxx
General Part Description
Analog output magnetometer or spin valve sensor
Analog output gradiometer
Digital output magnetometer
Evaluation kit or printed circuit board assembly
Digital output gradiometer
Custom digital output magnetometer
Digital input signal processing IC
Voltage regulator
Analog input signal processing IC
GMR Material Used In Product
No third letter indicates NVE’s standard multilayer material
High sensitivity, high temperature multilayer material
Low hysteresis, high temperature multilayer material
Spin valve material with synthetic anti-ferromagnet pinning
Consecutive Part Number
Meaning for AD-Series parts is described in the GMR Switch section of this
catalog; other products have numbers assigned consecutively with no meaning
implied
Two Digits
After Dash
-00
-01
-02
-07
-10
-11
-12
Final Letter
E
Package Type
MSOP 8 pin package
Raw IC (die); available in diced wafer on blue tape or waffle pack form
SOIC 8 pin package
Non-semiconductor style package; used for eval kits and PCBs
TDFN6 2.5mm X 2.5mm 6 pin package
PLLP6 3.0mm X 3.0mm 6 pin package
TDFN SO8 4.9mm X 6.0mm 8 pin package
Consecutive Part Number
No final letter means a standard package; E means a lead-free package
- 137 -
www.nve.com phone: 952-829-9217 fax: 952-829-9189
